MCCB/NFB 3P 40A 7,5KA/415VAC
| Pilih Jumlah kutub |
|
||||||||||||||||||||||||||||||||||||||||||||
| Pilih Arus pengenal |
|
||||||||||||||||||||||||||||||||||||||||||||
| Kode Produk | EZC100B3040 | ||||||||||||||||||||||||||||||||||||||||||||
| Nama Produk | MCCB/NFB 3P 40A 7,5KA/415VAC | ||||||||||||||||||||||||||||||||||||||||||||
| Keterangan | EZC100B SCHNEIDER ELECTRIC - EZC100B3040 | ||||||||||||||||||||||||||||||||||||||||||||
| Brand | Schneider Electric | ||||||||||||||||||||||||||||||||||||||||||||
| Poles | 3P | ||||||||||||||||||||||||||||||||||||||||||||
| Rated Current | 40A | ||||||||||||||||||||||||||||||||||||||||||||
| Breaking Capacity | 7.5kA | ||||||||||||||||||||||||||||||||||||||||||||
| Tipe | EasyPact EZC | ||||||||||||||||||||||||||||||||||||||||||||
| Ketersediaan Stok |
|
||||||||||||||||||||||||||||||||||||||||||||
|
Download the EZC100B3040 MCCB/NFB 3P 40A 7,5KA/415VAC SCHNEIDER ELECTRIC product datasheet, by clicking here! Function of the MCCB :
Schneider Electric - Easypact EZC Molded-circuit breakers (MCCBs) with fixed settings ranging from 15 to 630 A. Part of the Easy Series Moulded-circuit breakers (MCCBs) with fixed settings, rated from 15 to 630 A, are ideal for simple applications in small to medium-sized buildings. You can shop safely at ListrikKita.com because all the items we sell are guaranteed 100% original, officially guaranteed, and can be accompanied by a letter of authenticity of the goods. For more information or to make a large purchase, please contact our sales or marketing team by clicking here. Happy shopping! This is a 40A circuit breaker for EasyPact EZC100B. This product can work below rated operational voltage(Ue) 550VAC at 50/60Hz. The ultimate breaking capacity(Icu) is shown differently, depended on the condition of network, Ics=25%Icu if need to match. This version of product is designed 3 poles frame with detection on 3 poles,equiped TMD trip unit for thermal-magnetic protection. It is compliance with standard IEC60947, CE certification and some independent lab(KEMA,ASEFA,TUV) or third-party Tilva. This device is certified for operation in pollution degree III environment as defined by IEC60947, and pass the test of extremely atmospheric conditions. Device can be mounted vertically or horizontally in a metal enclosure,and against from safety risk by padlocking. The degree of protection is IP40 for direct rotary handle,and IP54 for extended rotary handle. This series have slots used for indication or voltage release auxiliaries positioning , depending on where it is inserted in the device behind the front cover of circuit breaker. The fixed dimension is 75mm(width),130mm(height),60mm(Depth). Specification
Documents
|
|||||||||||||||||||||||||||||||||||||||||||||
