Philips downlights are lamps that are hidden in the ceiling and have a directed and focused lighting effect for lighting that requires accents because they provide an elegant touch in a room. Philips downlights are suitable for highlighting the aesthetics and elegance of an architectural feature, work of art, or decorative element that makes a room look alive.
Philips downlights consist of 3 colors, namely warm white (3000 Kelvin), normal white (4000 Kelvin), and cool white (6500 Kelvin).
Some of the benefits of using Philips downlights are:
- Suitable for Limited Spaces
- Doesn't consume much energy
- The room looks more modern.
- Installation is flexible.
- Easy maintenance
- Simple structure
- Able to Help Create an Atmosphere
Specification
General information
- Replaceable light source : No
- Number of tool units : 1 unit
- Drivers covered : Yes
- Lighting Technology : LED
- Warranty period : 3 years
- The sign can light up : For installation on normally flammable surfaces
- Glow wire testing : Temperature 650 °C, duration 30 seconds
- EU RoHS compliant : Yes
Light Engineering
- Light Flux : 1.200 lm
- Correlated Color Temperature (Nom) : 3000 K
- Illumination Power (measured) (Nom) : 100,00 lm/W
- Color rendering index (CRI) : 80
- Light source color : 830 warm white
- Optical type : Light beam angle 110°
- Spread of luminaire light rays : 110°
Operation and Electrical
- Input Voltage : 220 to 240 V
- Line Frequency : 50 or 60 Hz
- Input Frequency : 50 or 60 Hz
- Current surge : 3,85 A
- Time came in suddenly : 0,101 ms
- Power Consumption : 12 W
- Power Factor (Fraction) : 0.9
- Cabel : 0.2 m cable without connector
- Number of products in MCB 16 A type B : 74
Temperature
- Ambient temperature range : -20 to +40 °C
Control and Dimming
- Dimmable : No
- Driver/power unit/transformer : Power supply unit (On/Off)
- Constant light output : No
Mechanical and Housing
- Housing material : Plastic Metal
- Reflector materials : -
- Optical materials : Polycarbonate
- Optical cover material : Polycarbonate
- Fixation material : Steel
- Housing Color : White
- Optical covering layer : Matte
- Overall length : 175 mm
- Overall width : 175 mm
- Overall height : 45 mm
- Overall diameter : 175 mm
- Dimensions (Length x Height x Width) : 45 x 175 x 175 mm
Consent and Application
- Dust and water ingress protection code : IP20/40 [Finger protection, Transmitting surface]
- Mechanical impact protection code : IK03 [0.3 J]
- IEC protection class : Class II security
Initial Performance (IEC Conformity)
- Light flux tolerance : +/-10%
- Initial chromaticity : (IEC3000K, 0.44, 0.403) ï¼ÂÂÂÂÂÂ5SDCM
- Power consumption tolerance: +/-10%
Performance Over Time (IEC Conformity)
- Driver failure rate at 5000 hours: 0,012 %
- Masa kegunaan median L70B50 : 30.000 hour
Application Conditions
- Suitable for random switches : No
