LIMIT SWITCH STANDARD XCKP STEEL ROLLER PLUNGER 1NC+1NO SLOW PG11 XCRT215EX
LIMIT SWITCH STANDARD XCKP STEEL ROLLER PLUNGER 1NC+1NO SLOW PG11
XCRT215EX
XCRT215EX

LIMIT SWITCH STANDARD XCKP STEEL ROLLER PLUNGER 1NC+1NO SLOW PG11

Kode Produk XCRT215EX
Nama Produk LIMIT SWITCH STANDARD XCKP STEEL ROLLER PLUNGER 1NC+1NO SLOW PG11
Keterangan LIMIT SWITCH TELEMECANIQUE - XCKP2502G11
Brand Telemecanique
Type Limit Switch
Ketersediaan Stok

To download the Datasheet TELEMECANIQUE XCRT215EX, please click here!

Main

  • Range of product : OsiSense ATEX D
  • Series name : special format
  • Product or component type : limit switch
  • Product specific application : for conveyor belt shift monitoring
  • Device short name : XCR
  • Body type : fixed
  • Head type : rotary head
  • Material : metal
  • Fixing mode : by the body
  • Movement of operating head : rotary
  • Type of operator : Spring return roller stainless steel with lever
  • Switch actuation : by conveyor belt
  • Type of approach : Lateral approach, 2 directions
  • Electrical connection : Screw-clamp terminals, clamping capacity: 1 x 0.5...2 x 2.5 mm²
  • Contacts type and composition : 2 x 1 C/O
  • Contacts insulation form : Za
  • Contact operation : snap action
  • Contact block per direction [control circuit] : 1 per direction
  • Positive opening : with
  • IP degree of protection : IP65 conforming to IEC 60529
  • Country of Origin : Prancis (France)

Packing Units

  • Unit Type of Package 1 : PCE
  • Number of Units in Package 1 : 1
  • Package 1 Height : 9.500 cm
  • Package 1 Width : 9.500 cm
  • Package 1 Length : 12.500 cm
  • Package 1 Weight : 1.295 g

You can shop safely at ListrikKita.com because all the goods we sell are guaranteed to be 100% genuine, have an official guarantee, and can be accompanied by a letter of authenticity. To get the best prices and further information, please contact our sales or marketing team by clicking here. Happy shopping.

Chat untuk Stock

Rp.25.918.094,-

38% Rp.41.803.377,-

Add to Cart

Free Ongkir Jabodetabek Menggunakan Kurir Toko Listrikkita
