DISCRETE I/O EXTENSION MODULE 6IO 24VAC FOR ZELIO LOGIC
DISCRETE I/O EXTENSION MODULE 6IO 24VAC FOR ZELIO LOGIC

DISCRETE I/O EXTENSION MODULE 6IO 24VAC FOR ZELIO LOGIC

Pilih Tegangan coil
Pilih I/o
Kode Produk SR3XT61B
Nama Produk DISCRETE I/O EXTENSION MODULE 6IO 24VAC FOR ZELIO LOGIC
Keterangan SMART RELAY SR3 MODUL EXTENSION I/O SCHNEIDER ELECTRIC - SR3XT61B
Brand Schneider Electric
Tegangan Coil 24VAC
Tipe Smart Relay SR2 & SR3
Ketersediaan Stok
Kode Produk : SR3XT61B Brand : Schneider Electric Nama Produk : DISCRETE I/O EXTENSION MODULE 6IO 24VAC FOR ZELIO LOGIC Keterangan : SMART RELAY SR3 MODUL EXTENSION I/O SCHNEIDER ELECTRIC - SR3XT61B

This product is part of Smart Relay Zelio Logic SR2/SR3, an offer of simple automation systems from 10 to 40 I/Os. This discrete I/O extension module offers 4 discrete inputs with 2 relay outputs. It is a module with discrete input voltage of 24V AC. It is an IP20 and IP40 rated product. It weighs 0.125kg. The main application of this module is industry and building/service sector. This product is certified by C-Tick, GL, UL, CSA and GOST. It meets EN/IEC 60068-2-27 Ea, EN/IEC 61000-4-5, EN/IEC 61000-4-12 and EN/IEC 61000-4-4 L3 standards. Easy to use, Zelio Logic provides a real alternative solutions based on cabled logic or specific cards.

Specification
Expandable FALSE
Number of HW-interfaces parallel 0
Supporting protocol for SERCOS FALSE
Number of interfaces PROFINET 0
Number of HW-interfaces other 0
Number of HW-interfaces serial TTY 0
Number of HW-interfaces USB 0
SIL according to IEC 61508 None
With optical interface FALSE
Number of HW-interfaces wireless 0
Performance level according to EN ISO 13849-1 None
Certified for UL hazardous location division 2 FALSE
Basic device TRUE
Radio standard GPRS FALSE
With relay output TRUE
Height 90 Millimetre
Supporting protocol for INTERBUS-Safety FALSE
Certified for UL hazardous location class I FALSE
Certified for UL hazardous location class III FALSE
Certified for UL hazardous location division 1 FALSE
Certified for UL hazardous location class II FALSE
Width 35 Millimetre
Supporting protocol for EtherCAT FALSE
Redundancy FALSE
Supporting protocol for AS-Interface Safety at Work FALSE
Radio standard GSM FALSE
Explosion safety category for dust None
Radio standard UMTS FALSE
Depth 59.5 Millimetre
Explosion safety category for gas None
Supporting protocol for DeviceNet Safety FALSE
Supporting protocol for EtherNet/IP FALSE
Supporting protocol for Foundation Fieldbus FALSE
Expansion device TRUE
Certified for UL hazardous location group C (ethylene) FALSE
Certified for UL hazardous location group A (acetylene) FALSE
Certified for UL hazardous location group B (hydrogen) FALSE
Certified for UL hazardous location group F (carbonaceous dusts) FALSE
Certified for UL hazardous location group G (non-conductive dusts) FALSE
Certified for UL hazardous location group D (propane) FALSE
Certified for UL hazardous location group E (metal dusts) FALSE
With display FALSE
Supporting protocol for SafetyBUS p FALSE
Voltage type (supply voltage) AC/DC
With time switch clock FALSE
Supporting protocol for PROFINET CBA FALSE
Supporting protocol for PROFINET IO FALSE
Supporting protocol for PROFIsafe FALSE
Radio standard Bluetooth FALSE
Supporting protocol for ASI FALSE
Radio standard WLAN 802.11 FALSE
Supporting protocol for PROFIBUS FALSE
Appendant operation agent (Ex ia) FALSE
Supply voltage AC 50 Hz 24 Volt
Supply voltage AC 60 Hz 24 Volt
Supporting protocol for TCP/IP FALSE
Front built-in possible TRUE
Supporting protocol for KNX FALSE
Supporting protocol for CAN FALSE
Appendant operation agent (Ex ib) FALSE
Degree of protection (IP) IP20
IO link master FALSE
Supporting protocol for INTERBUS FALSE
Rail mounting possible TRUE
Supporting protocol for DeviceNet FALSE
Number of digital outputs 2
Switching current 8 Ampere
Supporting protocol for Modbus FALSE
Suitable for safety functions FALSE
Number of digital inputs 4
Supporting protocol for Data-Highway FALSE
Number of analogue outputs 0
Rack-assembly possible FALSE
Number of analogue inputs 0
Power consumption 1.1 Watt
Supporting protocol for LON FALSE
Supporting protocol for other bus systems FALSE
Supporting protocol for SUCONET FALSE
Wall mounting/direct mounting TRUE
Number of HW-interfaces RS-422 0
Number of HW-interfaces RS-485 0
Number of HW-interfaces industrial Ethernet 0
Number of HW-interfaces RS-232 0
Documents
Image of product
Image of product

Chat untuk Stock

Rp.1.070.475,-

40% Rp.1.784.125,-

Add to Cart
